Hrc63 CNC Solid Carbide End Mills R1.0 10mm 12mm 4 Flute Corner Radius Cutting Tool

Hrc63 CNC Solid Carbide End Mills R1.0 10mm 12mm 4 Flute Corner Radius Cutting Tool
Hrc63 CNC Solid Carbide End Mills R1.0 10mm 12mm 4 Flute Corner Radius Cutting Tool Hrc63 CNC Solid Carbide End Mills R1.0 10mm 12mm 4 Flute Corner Radius Cutting Tool Hrc63 CNC Solid Carbide End Mills R1.0 10mm 12mm 4 Flute Corner Radius Cutting Tool Hrc63 CNC Solid Carbide End Mills R1.0 10mm 12mm 4 Flute Corner Radius Cutting Tool Hrc63 CNC Solid Carbide End Mills R1.0 10mm 12mm 4 Flute Corner Radius Cutting Tool

Large Image :  Hrc63 CNC Solid Carbide End Mills R1.0 10mm 12mm 4 Flute Corner Radius Cutting Tool

Product Details:
Place of Origin: Zhuzhou,China
Brand Name: Sanyinghe
Certification: ISO
Model Number: As your requirements
Payment & Shipping Terms:
Minimum Order Quantity: 5PCS
Price: Negotiable
Packaging Details: 1PCS In 1 Plastic Box, and Servel Boxes In 1 Carton.
Delivery Time: 7 days
Payment Terms: T/T, Western Union
Supply Ability: 3000pcs/month
Detailed Product Description
Material: Tungsten Carbide HRC: 63 Degree
Milling Machining: Side Milling, Slot Milling Helix Angle: Unequal Helix Angle
Usage: High Speed And High Efficiency Cutting Hardness Material Advantages: Unequal Helical Angle, Excellent Vibration Resistance
High Light:

CNC Solid Carbide End Mills

,

10mm Solid Carbide End Mills

,

12mm Corner Radius Cutting Tool

HRC63 Cnc Carbide End Mills R1.0 10mm 12mm 4 Flute Corner Radius Cutting Tools Machine Extra Long Milling Cutter

PRODUCT DESCRIPTION


1.Hardness:HRC45/50/55/60/65
2.Flutes:2 flutes or 4 flutes
3.Helix Angle: 35 degree or other
4.Centered Cutting: Yes
5.Type: Square End Mill / Flat end mill / Metal cutting tool
6.Workpiece material: Steel, mould steel, low alloy, hardened steel, staninless steel, alloy steel
7.Coating:TiAlN or other
8.Tool body material:Tungsten solid carbide



Product Name

Carbide End Mills
Material Carbide
HRC 63 Degree
Flute  4 Flute
Helix angle  Variable Helix
Processing material Suitable for all kinds of steel general processing series



Specifications
Cutting diameter
Flute length
Shank diameter
Overall length
Corner radius
Flute
D4x15x4x75L
4
15
4
75
R0.5/1.0
4
D4x20x4x100L
4
20
4
100
R0.5/1.0
4
D5x20x5x75L
5
20
5
75
R0.5/1.0
4
D5x25x5x100L
5
25
5
100
R0.5/1.0
4
D6x20x6x75L
6
20
6
75
R0.5/1.0
4
D6x25x6x100L
6
25
6
100
R0.5/1.0
4
D8x25x8x75L
8
25
8
75
R0.5/1.0
4
D8x30x8x100L
8
30
8
100
R0.5/1.0
4
D10x35x10x100L
10
35
10
100
R0.5/1.0
4
D10x45x10x150L
10
45
10
150
R0.5/1.0
4
D12x40x12x100L
12
40
12
100
R0.5/1.0
4
D12x50x12x150L
12
50
12
150
R0.5/1.0
4
D14x40x14x100L
14
40
14
100
R0.5/1.0/2.0
4
D14x50x14x150L
14
50
14
150
R0.5/1.0/2.0
4
D16x55x16x150L
16
55
16
150
R0.5/1.0/2.0/3.0
4
D18x55x18x150L
18
55
18
150
R0.5/1.0/2.0/3.0
4
D20x55x20x150L
20
55
20
150
R0.5/1.0/2.0/3.0
4

Hrc63 CNC Solid Carbide End Mills R1.0 10mm 12mm 4 Flute Corner Radius Cutting Tool 0Hrc63 CNC Solid Carbide End Mills R1.0 10mm 12mm 4 Flute Corner Radius Cutting Tool 1Hrc63 CNC Solid Carbide End Mills R1.0 10mm 12mm 4 Flute Corner Radius Cutting Tool 2



FAQ



1. Who are we?

Sanyinghe is professional cutting tool supplier founded in 2014. Sanyinghe has a excellent teams in designing and manufacturing. Welcome to contact with us, we can meet all your requirement.



2. How can we guarantee quality?

We own optimized design concept advanced testing equipment and strict production process, so we can guarantee quality steadily.



3. What can you buy from us?

We can provide you tungsten carbide end mills, tungsten carbide indexable inserts, cermet (metal ceramic) indexable inserts, tungsten carbide or HSS drills, and milling cutter head, milling cutter arbor, cnc tool holder,and so on.



4. How is the packing?

All the packing will meet the strict export packing requirement, we surely understand how important the beautiful and firm packaging to the goods.



5. What is your terms of payment?



Generally by T/T, Paypal, Western Union. We support EXW, FOB, FCA, CFR, CIF, and DDP Terms.
