Product Details:
Payment & Shipping Terms:
|
| Place Of Origin: | China | Model Number: | 15-60 |
|---|---|---|---|
| Type: | Taper Shank Cutter | Advantages: | Large Chip Removal, More Wear-resistant And Durable |
| High Light: | Taper Shank End Mill Cutting Tools,Alloy Inlaid End Mill Cutting Tools,reduced shank carbide end mill |
||
Product Description:
We can exceeds expectations in aggressive cutting parameters & advanced operations.The end mills are more productive, they can Improved chip evacuation & increased edge/corner strength to reduce any risk of breakage.and the can insure capable of machining a wide range of materials & operations.
The special front and rear corner cutter body is strong and high in hardness, which ensures repeated use and high precision. Rapid milling of alloy inlay materials, smooth chip removal and high cutting efficiency.
It has a long service life and wear resistance. More productive, they improve chip evacuation and increase edge/corner strength to reduce any risk of breakage.
The special flute design keeps the core diameter shrinking and gives it good rigidity.
Specifications:
| Material | 45 gauge steel |
| Packing | 1ps/ Plastic Box |
| Suitable | Iron/Aluminum/Bronze/Steel |
| Shank Shape | taper shank |
Note:
These sizes we have in stock, and the other sizes,we can produce for you based on your requirements. Any need, please free comments.
| Type | Bore | Total length | Taper shank | Number of blades |
| 15 | 5 | 130 | 2 | 4 |
| 16 | 5 | 130 | 2 | 4 |
| 18 | 5 | 130 | 2 | 4 |
| 20 | 6 | 160 | 2 | 4 |
| 22 | 6 | 160 | 2 | 4 |
| 24 | 6 | 180 | 3 | 4 |
| 25 | 6 | 180 | 3 | 4 |
| 26 | 8 | 180 | 3 | 4 |
| 28 | 8 | 180 | 3 | 4 |
| 30 | 8 | 180 | 3 | 4 |
| 32 | 8 | 180 | 3 | 4 |
| 34 | 10 | 220 | 4 | 4 |
| 35 | 10 | 220 | 4 | 4 |
| 36 | 10 | 220 | 4 | 4 |
| 38 | 10 | 220 | 4 | 4 |
| 40 | 10 | 220 | 4 | 4 |
| 42 | 10 | 220 | 4 | 4 |
| 45 | 10 | 220 | 4 | 4 |
| 46 | 10 | 220 | 4 | 4 |
| 48 | 10 | 220 | 4 | 4 |
| 50 | 10 | 220 | 4 | 4 |
| 55 | 10 | 220 | 4 | 4 |
| 60 | 10 | 220 | 4 | 4 |
