Product Details:
Payment & Shipping Terms:
|
| Material: | Tungsten Carbide | Name: | End Mill, Square Milling Cutter |
|---|---|---|---|
| Machine: | CNC Tool And Cutter Grinder Machines | Standard Size: | 4mm,6mm,8mm,10mm,12mm,14mm,16mm,18mm,20mm |
| High Light: | 6 Flute Burr End Mill,Carbide Burr End Mill,4mm Tungsten Carbide Tool |
||
PRODUCT DESCRIPTION
1. Super Micro Grain Carbide Raw Material.
2. 45° Perfect Helix Angle.
3. Durable Coating, Superior Wear Resistance.
4. Excellent hot hardness and Oxidation resistance.
5. Suitable for Stainless Steel, Mould Steel, Alloy Steel, Tool Steel, Iron, Carbon Iron, Cast Iron, etc.
6. Sharp & High-Precision Cutting Edge, Able to machining high-hardness Steel at high speed.
7. Different standard sizes are all availalbe at stock.
|
Flute diameter |
Flute length | Overall length | Shank diameter | Flute diameter | Flute length | Overall length | Shank diameter |
| 0.3-0.6 | 1.5 | 50 | ∅4 | ∅5 | 13 | 50 | ∅6 |
| 0.7-0.8 | 2.5 | 50 | ∅4 | ∅6 | 15 | 50 | ∅6 |
| ∅1 | 3 | 50 | ∅4 | ∅7 | 18 | 60 | ∅8 |
| ∅1.5 | 4 | 50 | ∅4 | ∅8 | 20 | 60 | ∅8 |
| ∅2 | 5 | 50 | ∅4 | ∅9 | 22 | 75 | ∅10 |
| ∅2.5 | 6 | 50 | ∅4 | ∅10 | 30 | 75 | ∅10 |
| ∅3 | 8 | 50 | ∅3 | ∅12 | 30 | 75 | ∅12 |
| ∅3.5 | 9 | 50 | ∅4 | ∅14 | 40 | 100 | ∅14 |
| ∅4 | 10 | 50 | ∅4 | ∅16 | 40 | 100 | ∅16 |
| Flute diameter | Flute length | Overall length | Shank diameter | Flute diameter | Flute length | Overall length | Shank siameter |
| ∅18 | 40 | 100 | ∅18 | ∅4 | 15 | 75 | ∅4 |
| ∅20 | 45 | 100 | ∅20 | ∅5 | 20 | 75 | ∅6 |
| ∅3 | 12 | 75 | ∅4 | ∅6 | 24 | 75 | ∅6 |
FAQ
1. Who are we?
Sanyinghe is professional cutting tool supplier founded in 2014. Sanyinghe has a excellent teams in designing and manufacturing. Welcome to contact with us, we can meet all your requirement.
2. How can we guarantee quality?
We own optimized design concept advanced testing equipment and strict production process, so we can guarantee quality steadily.
3. What can you buy from us?
We can provide you tungsten carbide end mills, tungsten carbide indexable inserts, cermet (metal ceramic) indexable inserts, tungsten carbide or HSS drills, and milling cutter head, milling cutter arbor, cnc tool holder,and so on.
4. How is the packing?
All the packing will meet the strict export packing requirement, we surely understand how important the beautiful and firm packaging to the goods.
5. What is your terms of payment?
Generally by T/T, Paypal, Western Union. We support EXW, FOB, FCA, CFR, CIF, and DDP Terms.
