Product Details:
Payment & Shipping Terms:
|
| Material: | Carbide | Usage: | Carbon Steel, Alloy Steel, Cast Iron |
|---|---|---|---|
| Flutes: | 1/2/3/4 Flutes | OEM: | Yes |
| Machine Type: | Miling Machine | Coating: | AlTiN, TiAIN, TiN, NANO |
| High Light: | Carbide Corner Radius End Mill,4 Flutes Carbide Corner Radius End Mill,OEM Solid Carbide Cutting Tools |
||
PRODUCT DESCRIPTION
1. Surface TISIN Coatedl
2. Strength2500-4000N/mm2 Controling ModeCNC
3. UsageMetal Chemical Composition6%-12%Co-WC
4. Density14.45-14.90g/cm3
5. Chemical Composition: 10%Co-Wc
6. Raw Material: Super Micro grain with Diameter less than 0.2UM
7. International Industrial Standard: K10, K05-K15, K20-K30, K20-K40
8. Application areas: Machining of cast iron, nonferrous alloy,chill cast iron,hard steel,stainless steel,plastic materials,fiberglass,carbon fiber and other non-metallic.
9. Served industries: Aerospace,Transportation, Medical Equipment,Military Manufacturing,Mold Development,etc.
| Material | Tungsten carbide |
| Coating | AITiN or as you request |
| Hardness(HV) | 1475~1675 |
| Hardness(HRC) | 45/50/55/60/65 |
| Size | Dia:1-25mm,Overal Length:50-250mm |
| Smooth Finish | Highly Polished |
|
Corner Radius End Mill
|
Specification-R0.2
|
Flute
|
|
1
|
D1R0.2*3*D4*50L
|
4
|
|
2
|
D1.5R0.2*4.5*D4*50L
|
4
|
|
3
|
D2R0.2*6*D4*50L
|
4
|
|
4
|
D2.5R0.2*7.5*D4*50L
|
4
|
|
5
|
D3R0.2*9*D4*50L
|
4
|
|
6
|
D4R0.2*12*D4*50L
|
4
|
|
7
|
D6R0.2*15*D6*50L
|
4
|
|
8
|
D8R0.2*20*D8*60L
|
4
|
|
Corner Radius End Mill
|
Specification-R0.5
|
Flute
|
|
1
|
D2R0.5*6*D4*50L
|
4
|
|
2
|
D2.5R0.5*7.5*D4*50L
|
4
|
|
3
|
D3R0.5*9*D4*50L
|
4
|
|
4
|
D3.5R0.5*10.5*D4*50L
|
4
|
|
5
|
D4R0.5*12*D4*50L
|
4
|
|
6
|
D4R0.5*14*D4*75L
|
4
|
|
7
|
D4R0.5*16*D4*100L
|
4
|
|
8
|
D5R0.5*12.5*D5*50L
|
4
|
|
9
|
D6R0.5*15*D6*50L
|
4
|
|
10
|
D6R0.5*20*D6*75L
|
4
|
|
11
|
D6R0.5*25*D6*100L
|
4
|
|
12
|
D8R0.5*20*D8*60L
|
4
|
|
13
|
D8R0.5*25*D8*75L
|
4
|
|
14
|
D8R0.5*30*D8*100L
|
4
|
|
15
|
D10R0.5*25*D10*75L
|
4
|
|
16
|
D10R0.5*30*D10*100L
|
4
|
|
17
|
D12R0.5*30*D12*75L
|
4
|
|
18
|
D12R0.5*35*D12*100L
|
4
|
|
Corner Radius End Mill
|
Specification-R1
|
Flute
|
|
1
|
D3R1*9*D4*50L
|
4
|
|
2
|
D3R1*9*D3*50L
|
4
|
|
3
|
D4R1*12*D4*50L
|
4
|
|
4
|
D4R1*14*D4*75L
|
4
|
|
5
|
D4R1*16*D4*100L
|
4
|
|
6
|
D5R1*12.5*D5*50L
|
4
|
|
7
|
D5R1*15*D5*75L
|
4
|
|
8
|
D5R1*12.5*D6*50L
|
4
|
|
9
|
D6R1*15*D6*50L
|
4
|
|
10
|
D6R1*20*D6*75L
|
4
|
|
11
|
D6R1*25*D6*100L
|
4
|
|
12
|
D8R1*20*D8*60L
|
4
|
|
13
|
D8R1*25*D8*75L
|
4
|
|
14
|
D8R1*30*D8*100L
|
4
|
|
15
|
D10R1*25*D10*75L
|
4
|
|
16
|
D10R1*30*D10*100L
|
4
|
|
17
|
D12R1*30*D12*75L
|
4
|
|
19
|
D12R1*35*D12*100L
|
4
|
|
Corner Radius End Mill
|
Specification-R2
|
Flute
|
|
1
|
D8R2*20*D8*60L
|
4
|
|
2
|
D10R2*25*D10*75L
|
4
|
|
3
|
D12R2*30*D12*75L
|
4
|
