Product Details:
Payment & Shipping Terms:
|
| Material: | Tungsten Carbide | Type: | CNC Milling Cutter |
|---|---|---|---|
| Size: | 1-20mm | Application: | Face Mill,CNC Machining Center |
| Workpiece: | Copper, Steel, Stainless Steel, Carbon Steel, Alloy Steel, Die | ||
| High Light: | 3mm Carbide Corner Radius End Mill,4mm Carbide Corner Radius End Mill,CNC High Speed Cutting Tool |
||
PRODUCT DESCRIPTION
| Flute | 2/3/4Flutes |
| Color | Black/Bronze/Blue/Golden |
| Suitable for | face mill,CNC machining center |
| Material | Tungsten Carbide |
| Diameter | 1-20mm |
| Overall Length | 50-150mm |
|
Corner Radius End Mill
|
Specification-R0.2
|
Flute
|
|
1
|
D1R0.2*3*D4*50L
|
4
|
|
2
|
D1.5R0.2*4.5*D4*50L
|
4
|
|
3
|
D2R0.2*6*D4*50L
|
4
|
|
4
|
D2.5R0.2*7.5*D4*50L
|
4
|
|
5
|
D3R0.2*9*D4*50L
|
4
|
|
6
|
D4R0.2*12*D4*50L
|
4
|
|
7
|
D6R0.2*15*D6*50L
|
4
|
|
8
|
D8R0.2*20*D8*60L
|
4
|
|
Corner Radius End Mill
|
Specification-R0.5
|
Flute
|
|
1
|
D2R0.5*6*D4*50L
|
4
|
|
2
|
D2.5R0.5*7.5*D4*50L
|
4
|
|
3
|
D3R0.5*9*D4*50L
|
4
|
|
4
|
D3.5R0.5*10.5*D4*50L
|
4
|
|
5
|
D4R0.5*12*D4*50L
|
4
|
|
6
|
D4R0.5*14*D4*75L
|
4
|
|
7
|
D4R0.5*16*D4*100L
|
4
|
|
8
|
D5R0.5*12.5*D5*50L
|
4
|
|
9
|
D6R0.5*15*D6*50L
|
4
|
|
10
|
D6R0.5*20*D6*75L
|
4
|
|
11
|
D6R0.5*25*D6*100L
|
4
|
|
12
|
D8R0.5*20*D8*60L
|
4
|
|
13
|
D8R0.5*25*D8*75L
|
4
|
|
14
|
D8R0.5*30*D8*100L
|
4
|
|
15
|
D10R0.5*25*D10*75L
|
4
|
|
16
|
D10R0.5*30*D10*100L
|
4
|
|
17
|
D12R0.5*30*D12*75L
|
4
|
|
18
|
D12R0.5*35*D12*100L
|
4
|
|
Corner Radius End Mill
|
Specification-R1
|
Flute
|
|
1
|
D3R1*9*D4*50L
|
4
|
|
2
|
D3R1*9*D3*50L
|
4
|
|
3
|
D4R1*12*D4*50L
|
4
|
|
4
|
D4R1*14*D4*75L
|
4
|
|
5
|
D4R1*16*D4*100L
|
4
|
|
6
|
D5R1*12.5*D5*50L
|
4
|
|
7
|
D5R1*15*D5*75L
|
4
|
|
8
|
D5R1*12.5*D6*50L
|
4
|
|
9
|
D6R1*15*D6*50L
|
4
|
|
10
|
D6R1*20*D6*75L
|
4
|
|
11
|
D6R1*25*D6*100L
|
4
|
|
12
|
D8R1*20*D8*60L
|
4
|
|
13
|
D8R1*25*D8*75L
|
4
|
|
14
|
D8R1*30*D8*100L
|
4
|
|
15
|
D10R1*25*D10*75L
|
4
|
|
16
|
D10R1*30*D10*100L
|
4
|
|
17
|
D12R1*30*D12*75L
|
4
|
|
19
|
D12R1*35*D12*100L
|
4
|
|
Corner Radius End Mill
|
Specification-R2
|
Flute
|
|
1
|
D8R2*20*D8*60L
|
4
|
|
2
|
D10R2*25*D10*75L
|
4
|
|
3
|
D12R2*30*D12*75L
|
4
|
FAQ
1. Who are we?
Sanyinghe is professional cutting tool supplier founded in 2014. Sanyinghe has a excellent teams in designing and manufacturing. Welcome to contact with us, we can meet all your requirement.
2. How can we guarantee quality?
We own optimized design concept advanced testing equipment and strict production process, so we can guarantee quality steadily.
3. What can you buy from us?
We can provide you tungsten carbide end mills, tungsten carbide indexable inserts, cermet (metal ceramic) indexable inserts, tungsten carbide or HSS drills, and milling cutter head, milling cutter arbor, cnc tool holder,and so on.
4. How is the packing?
All the packing will meet the strict export packing requirement, we surely understand how important the beautiful and firm packaging to the goods.
5. What is your terms of payment?
Generally by T/T, Paypal, Western Union. We support EXW, FOB, FCA, CFR, CIF, and DDP Terms.
