Product Details:
Payment & Shipping Terms:
|
| Features: | Excellent Workpiece Finishes,suprior Wear-resitance. | Material: | Tungsten Carbide |
|---|---|---|---|
| Usage: | CNC Machine Center | OEM:: | Yes |
| High Light: | 20mm Carbide Corner Radius End Mill,Tungsten Carbide Corner Radius End Mill,CNC Tungsten Carbide End Mill |
||
PRODUCT DESCRIPTION
1.Hardness:HRC45/50/55/60/65
2.Flutes:2 flutes or 4 flutes
3.Helix Angle: 35 degree
4.Centered Cutting: Yes
5.Type: Square End Mill / Flat end mill / Metal cutting tool
6.Workpiece material: Steel, mould steel, low alloy, hardened steel, staninless steel, alloy steel
7.general high speed cutting for metal
8.Coating:TiAlN
9.Tool body material:Tungsten solid carbide
10.Color: Black, yellow
11.Customized requirements.
| Flutes No. | 2/3/4 Flutes |
| Material | HSS,Carbide etc. |
| Coating | AlTiN,NACO BLUE/NACO BLACK/TiN etc. |
| Helix Angle | 35°,45° |
| Hardness | HRC45/55/58/65 |
| Size | Overal Length:50-150mm |
| Customized | Accept |
| Smooth Finish | Highly Polished |
| Feature | Excellent chip evacuation |
| Measurement | Metric |
Unit:mm
| specification | cutting | shank diamete | flute length | overall |
| D2.0*6*D4*75L | 2.0 | 4 | 6 | 75 |
| D4.0*11*D4*75L | 4.0 | 4 | 11 | 75 |
| D6.0*15*D6*75L | 6.0 | 6 | 15 | 75 |
| D8.0*20*D8*75L | 8.0 | 8 | 20 | 75 |
| D4.0*8*D6*100L | 4.0 | 6 | 8 | 100 |
| D6.0*15*D6*100L | 6.0 | 6 | 15 | 100 |
| D8.0*20*D8*100L | 8.0 | 8 | 20 | 100 |
| D10.0*25*D10*100L | 10.0 | 10 | 25 | 100 |
| D12.0*30*D12*100L | 12.0 | 12 | 30 | 100 |
| D16.0*40*D16*100L | 16.0 | 16 | 40 | 150 |
| HRC45 | HRC55 | HRC60 | HRC65 |
| YG10X | YG10.2 &WF25(Taiwan) | K44 & K40 (German) | H10F (Sweden) |
| Grain Size:0.7um Co:10 % Flexural strength:3320N/mm2 |
Grain Size:0.6um Co:10 % Flexural strength:4000N/mm2 |
Grain Size:0.5um Co:12 % Flexural strength:4300N/mm2 |
Grain Size:0.5um Co:10 % Flexural strength:4300N/mm2 |
FAQ
1. Who are we?
Sanyinghe is professional cutting tool supplier founded in 2014. Sanyinghe has a excellent teams in designing and manufacturing. Welcome to contact with us, we can meet all your requirement.
2. How can we guarantee quality?
We own optimized design concept advanced testing equipment and strict production process, so we can guarantee quality steadily.
3. What can you buy from us?
We can provide you tungsten carbide end mills, tungsten carbide indexable inserts, cermet (metal ceramic) indexable inserts, tungsten carbide or HSS drills, and milling cutter head, milling cutter arbor, cnc tool holder,and so on.
4. How is the packing?
All the packing will meet the strict export packing requirement, we surely understand how important the beautiful and firm packaging to the goods.
5. What is your terms of payment?
Generally by T/T, Paypal, Western Union. We support EXW, FOB, FCA, CFR, CIF, and DDP Terms.
