HRC55 Side And Face Milling Cutter 10mm CNC Carbide Flat End Mill

HRC55 Side And Face Milling Cutter 10mm CNC Carbide Flat End Mill
HRC55 Side And Face Milling Cutter 10mm CNC Carbide Flat End Mill HRC55 Side And Face Milling Cutter 10mm CNC Carbide Flat End Mill HRC55 Side And Face Milling Cutter 10mm CNC Carbide Flat End Mill HRC55 Side And Face Milling Cutter 10mm CNC Carbide Flat End Mill HRC55 Side And Face Milling Cutter 10mm CNC Carbide Flat End Mill HRC55 Side And Face Milling Cutter 10mm CNC Carbide Flat End Mill

Large Image :  HRC55 Side And Face Milling Cutter 10mm CNC Carbide Flat End Mill

Product Details:
Place of Origin: Zhuzhou,China
Brand Name: Sanyinghe
Certification: ISO
Model Number: D4/6/8/10/12/16/20mm
Payment & Shipping Terms:
Minimum Order Quantity: 5PCS
Price: Negotiable
Packaging Details: 1PCS In 1 Plastic Box, and Servel Boxes In 1 Carton.
Delivery Time: 5-7 days
Payment Terms: T/T, Western Union
Supply Ability: 3000pcs/month
Detailed Product Description
Material: Tungsten Carbide Processing Type: Semi-finish
Advantages: Wear Resistance Suitable For: Cooper.Cast Iron.Carbon Steel.Mould Steel
Usage: General High Speed Cutting For Metal Application: Side Machining,step Shoulder,Straight Slot
High Light:

HRC55 Side And Face Milling Cutter

,

10mm side and face milling cutter

,

CNC Carbide Flat End Mill

HRC55 CNC Carbide Milling Cutter 10mm Face Milling And Side Milling Flat Square End Mill Cuting Tool For Stainless Steel



PRODUCT DESCRIPTION

1.Well wear resistance.
2.Size: dia 0.5mm-30mm,overal length:50mm to 200mm.
3.No. of flute: 2/3/4/6 futes.
4.Work piece:copper & aluminium alloy,general steel,stainless steel,titanium alloy,hest-resistant super alloy,hardened steel,wood,dfrp.
5.Type: solid carbide square/(taper) ball nose end mill/corner radius end mills.
Applications of square end mill
1.Suitable for Copper, Cast Iron, Carbon steel, Tool steel, Mould steel, Die steel, Stainless steel, Plastic, Arcylic, etc.
2.Applicated for Aerospace, transportation, Medical equipment, military manufacturing, mould development, apparatus and instrument, etc.





Product Name

Carbide End Mills
Material Carbide, Tungsten carbide
Precision 0.005-0.01 (high precision)
Processing Type Finishing Maching
Suitable For wood, cast iron, carbon steel, mould steel, stainless steel, titanium alloy, tool steel, and heat-treated steel, etc.
Model customized is acceptable







Endmill Grade
Coating Name
Color
Hv
μm
Friction
The MaxºC
Application
HRC 45° coating
AlTiN
black
3300
0.6
0.7
850ºC
Suitable for General Steel
HRC 50° coating
AlTiN
black
3300
0.6
0.7
850ºC
Suitable for General Steel
HRC 55° coating
TiSiAlN
bronzed
3400
0.5
0.7
900ºC
General Steel,cast cast iron
HRC 60° coating
AlCrSiN
black
4000
0.4
0.35
1100ºC
High Hard Material, steel, cast iron, etc
HRC 65° coating
nACo 3 Blue
blue
4500
0.4
0.45
1200ºC
Titanium Alloy, High-temperature Alloy,material, etc
HSS
nACo 3 Blue
Other
4500
0.4
0.45
1200ºC
Stainless steel



4 Flute End Mill
d
L2
L
D
4
10
50
4
6
15
50
6
8
20
60
8
10
25
75
10
12
30
75
12
14
45
100
16
18
45
100
18
20
45
100
20



HRC55 Side And Face Milling Cutter 10mm CNC Carbide Flat End Mill 0HRC55 Side And Face Milling Cutter 10mm CNC Carbide Flat End Mill 1HRC55 Side And Face Milling Cutter 10mm CNC Carbide Flat End Mill 2

FAQ



1. Who are we?

Sanyinghe is professional cutting tool supplier founded in 2014. Sanyinghe has a excellent teams in designing and manufacturing. Welcome to contact with us, we can meet all your requirement.



2. How can we guarantee quality?

We own optimized design concept advanced testing equipment and strict production process, so we can guarantee quality steadily.



3. What can you buy from us?

We can provide you tungsten carbide end mills, tungsten carbide indexable inserts, cermet (metal ceramic) indexable inserts, tungsten carbide or HSS drills, and milling cutter head, milling cutter arbor, cnc tool holder,and so on.



4. How is the packing?

All the packing will meet the strict export packing requirement, we surely understand how important the beautiful and firm packaging to the goods.



5. What is your terms of payment?



Generally by T/T, Paypal, Western Union. We support EXW, FOB, FCA, CFR, CIF, and DDP Terms.
